146*190mm 24/48V DC Double Inlet Centrifugal Blower Fan

146*190mm 24/48V DC Double Inlet Centrifugal Blower Fan

SKU:
SGF146/190D2B2, SGF146/190D4B2

Impeller Size: 146*190mm

Impeller Material: Galvanized Sheet Steel

Motor Type: BLDC External Rotor Motor

Bearing: Ball Bearing

Speed Control:0-10VDC/PWM

Signal Output: FG

Protection Type: IP44

Insulation Class: B

Motor Protection: Locked-Rotor/Reverse Polarity/Over Voltage/Soft Start

Product Parameters

Model Rated Voltage Operating
Voltage
Rated Current Rated Power Rated Speed Air Flow Air pressure Noise Level Perm.Amb.
Temp.
Weight
Part NO. VDC VDC A W RPM M³/h Pa dBA ºC Kg
SGF146/190D2B2 24 16~28 6.4 153 1580 810 410 61 -25~+60ºC 3.4
SGF146/190D4B2 48 36~56 3.2 153 1580 810 410 61 -25~+60ºC 3.4
A forward curved centrifugal fan is shaped like a cylinder and small blades fall on the circumference of the impeller.
The operation of a forward curved centrifugal fan requires a housing that converts high velocity air leaving the tips of the impeller blade into a lower velocity static force and directs the air flow to the outlet. The double inlet blower has a wider scroll housing drawing air in from both sides of the scroll delivering it to the wider square outlet.
Double inlet centrifugal fans are suitable for any lower pressure applications requiring a high-volume flow particularly in small spaces.
